PND navigation
PND-1010
Selling Points
- Supports 10.1”IPS panel
- Support capacitive touch
- Android 12+ operating system, support for Google Store
- Support 1080P rear camera, can realize the rear picture preview and reverse view
- Support Android Auto and Carplay to achieve screen projection function
- Support Bluetooth 5.0, realize Bluetooth call and Bluetooth music
- Support WiFi and FM,external GPS+BDS dual-mode GPS antenna
- Support 4G(FDD-LTE: B1/B3/B5/B7/B8/B20,TDD-LTE: B38/B39/B40/B41,WCMDA: B1/B8/B2/B5)
- Supports local upgrade and OTA upgrade
- Supports AUX audio output
Specifications
Technical Specifications
| Product Type | Car Headrest Display |
|---|---|
| Model | PND-1010 |
| OS | Android 12+ |
| CPU | UIS7861 8Core 2*A75/1.6GHz+6*A55/1.6GHz |
| LCD | 10.1" IPS (1280×800) |
| TP | Capacitive Touch Screen |
| RAM | DDR:4GB |
| FLASH ROM | eMMC:64GB |
| SD Card | 256G (MAX) |
| Software Feature | Supports AUX audio output |
| GPS | External GPS，Supports GPS and BDS |
| BT | Bluetooth 5.0 |
| WIFI | Dual band: 2.4G/5GHz |
| 4G | CAT7 |
| 4G Band | FDD-LTE: B1/B3/B26（B5.B18.B19)/B7/B8/B20/B28FTDD-LTE: B38/B39/B40/B41WCMDA:B1/B5/B8 |
| FM transmit | Support 76-108MHz (Default 88-108MHz) |
| AUX | 2-in-1 car charger comes with ports |
| Speaker | Build-in 8R/2W Speaker |
| Charger | TYPE-C 5V/3A |
| Battery | Super Capacitor 5.5V/5F |
| Operating Temperature | -10℃--- +60 |
| Storage Temperature | -20℃--- +70 |
| Weight | 151g |
| Dimension | 240.89*154.1*70MM |
